Application
Honeycomb paper core sleeve making machine is eco-friendly and cost effective alternative for plastic bubble wrap cushioning. It is easy to open to provide cushion protect without surface scratch to the item packing.Finished products from this machine can be used to pack bottle, fruits, flowers, ceramics, glassware etc.
Technical parameters
| Machine model | EM-PC900 |
| Paper thickness | 50～70g |
| Machine working speed | 4pcs-12pcs/min(if finished length is 220mm,can do 3pcs by one time,so speed is 12pcs/min) |
| Feeding box | 30-50pcs cores feeding/group |
| Paper core height | 10-15mm |
| Paper core width | 80-160 layers (10-20mm) |
| Paper core length | 200-900mm (220mm,350mm,450mm most common),
if do 220mm,can be 4 cores feeding by one time, if 350mm,can be 2 cores feeding by one time |
| Power | 3kw |
| Machine size | 1500*800*1300mm(LxWxH) |
| Machine weight | 500KG |
| Power supply | 380V 3 Phase or as customer requirement |
